Poor Man's Autograd

Mar 27, 2026
Section: Home / Post
Categories: Machine Learning,
Tags: Neural Networks, Llm, Graphs,

I recently came across microgpt - a single-file, python-only training script for a GPT model.

What stood out to me were 40 or so lines that implemented autograd. That is, calculating gradients of computations done in code, automatically. Autograd is not novel (python autograd). It underpins every single deep learning library (jax, torch, tensorflow, and yes, numpy too).

No, the reason I was so taken aback was explicitly facing the simplicity of the mechanism that has fueled machine learning for decades now. It’s one thing to call loss.backward(); it’s an entirely different thing to pause and examine what’s happening underneath.

The goal of this post is to build up those 40 lines, step by step. First, we revisit two rules of differentiation. Then we come up with a representation of differentiable values in code. Finally, we apply the two rules over a few revisions, each more complex.

The Chain Rule

The derivative multiplies over function composition.

$$ \frac{\partial}{\partial{x}} f(g(x)) = \frac{\partial}{\partial g}f \cdot \frac{\partial}{\partial x} g $$

For example:

$$ f = g(x)^2\\ g(x) = kx \\ \frac{\partial}{\partial{x}}f = \frac{\partial}{\partial g}(g(x)^2)\cdot \frac{\partial}{\partial x} (kx)\\ = (2 \cdot g(x)) \cdot k \\ = 2 k^2 x $$

Note:

  graph LR

x[x]
g["g(x)"]
f["f(g(x))"]

x --"dg/dx"--> g
g --"df/dg"--> f

Looking at the graph, edges defining a path backwards from f to x are multiplied. The effect of each function composition is multiplicative.

The distributive property

The derivative is distributive over addition.

$$ \frac{\partial}{\partial x} (f(x) + g(x)) = \frac{\partial}{\partial x} f(x) + \frac{\partial}{\partial x} g(x) $$

For example:

$$ f = g(x) + 2x \\ g(x) = kx \\ \frac{\partial}{\partial{x}}f = \frac{\partial}{\partial x}(g(x)) + \frac{\partial}{\partial x}(2x) \\ = \left(\frac{\partial}{\partial g}(g(x))\cdot \frac{\partial}{\partial x} (kx) \right) + \frac{\partial}{\partial x}(2x) \\ = (1 \cdot k) + 2 $$

Note:

  graph LR

x[x]
g["g(x)"]
f["f(x)"]
two["2x"]

x --"dg/dx"--> g
g --"df/dg"--> f
x --"d(2x)/dx"--> two
two --"df/d(2x)"--> f

Looking at the graph, $x$ affects $f(x)$ twice: once through $g(x)$ and once through $2x$. Visually, the change in $f$ with respect to $x$ should add the change due to each of the two branches.

Representing a differentiable value

We need to represent each scalar such that we can contain its value and gradient. Each operation produces a new value.

1
2
3
4
5
6
7
8
9
class Value:
    def __init__(self, data, grad=None):
        self.data = data
        self.grad = grad

    def __add__(self, other):
        result = self.data + other.data
        result_node = Value(data=result)
        return result_node

Let’s try it out:

1
2
3
4
5
w = Value(2)
x = Value(1)
y = w + x
z = y + x
print(z.data)

  graph LR
w --"dy/dw"--> y
y --"dz/dy"--> z
x --"dy/dx"--> y
x --"dz/dx"--> z

Backward pass on the computation graph

Now, we need a backward pass. What is dz/d[w,x,y]? Note that each intermediate result, starting from the inputs, is a Value object. Also note that the relationships lend themselves to a graph representation. We can call each Value, be it input, intermediate, or output, a node in the computation graph.

Note that the gradients from the two edges to x get added (the distributive property). One path has multiple hops y--z and x--y. Their gradients get multiplied (the chain rule), before being accumulated into x.

Since, there are multiple paths back from z to x. Therefore, x needs to keep track of all the gradients it has accumulated so far. This can be done in the grad attribute.

To traverse edges, we need to track the dependencies of each node. Then we can calculate, for each operation (i.e. edge), d node / d dependency. For addition, dependencies are the two arguments into the add operation. They can be tracked as a tuple attribute deps. The pesudocode for an add operation is:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
 y = w + x
 z = y + x

 # dz/dx = [dz/dy * dy/dx] + dz/dx
 #         \--chain rule--/
 #         \--distributive property--/

 # Starting from the final node
 for dep in z.deps: # i.e. y, x
     # new gradient =
     dep.grad = \
        # current gradient (distributive property)
        dep.grad + # it's 0 for now \
        # parent's gradient (dz/dz) * gradient of add operation (chain rule)
        (z.grad * 1)

 # Then proceeding down the graph to the deps of deps
 for dep in y.deps: # i.e. w, x
     # new gradient =
     dep.grad = \
        # current gradient (distributive property)
        dep.grad + # non-zero for x; it was visited earlier ^^ \
        # parent's gradient (dz/dy) * gradient of add operation (chain rule)
        (y.grad * 1)

Putting it together as follows. A backward() method is defined which calculates the derivative with respect to each node in the computation graph. We make two observations when giving grad a default value:

When calling backward() on a node, the most trivial gradient is that of the node with itself. d node / d node = 1. The first thing we check in backward() is whether grad is None. If so, we know that that node is the root node from which backward() was first called.
When looking at a node’s dependencies, we want to respect other gradients that may have accumulated from other edges in the computation graph. We check whether the grad attribute of a dependency is None. If so, it means that that dependency hasn’t started accumulating gradients. We set it to 0. (Why not set to 1? We only set 1 for the root node. Since this is necessarily a dependency of some node, therefore it is not the root node.)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
class Value:
    def __init__(self, data, grad=None, deps=()):
        self.data = data
        self.grad = grad
        self.deps = deps
    def __repr__(self): return f"V({self.data}, {self.grad})"
    def __add__(self, other):
        data = self.data + other.data
        deps = (self, other)
        return Value(data=data, grad=None, deps=deps)
    def backward(self):
        # The root node: d(root)/d root = 1
        if self.grad is None:
            self.grad = 1
        for dep in self.deps:
            # This is the first time the dependency is seen.
            # It does not have any gradients accumulated.
            if dep.grad is None:
                dep.grad = 0
            # accumulating edges = last total + gradient of current edge
            dep.grad = dep.grad + (self.grad * 1)
            dep.backward()

Let’s try it out:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
w = Value(2)
x = Value(1)
y = w + x
z = y + x
# z = (w+x) + x = w + 2x
# dz/dx = 2, dz/dy = 1, dz/dw = 1
print("z", z)

z.backward()
print(f"dz/dz: {z.grad}")
print(f"dz/dy: {y.grad}")
print(f"dz/dx: {x.grad}")
print(f"dz/dw: {w.grad}")

Adding operations

Looking closely at the gradient accumulation line, let’s think from the perspective of y:

1
 dep.grad = dep.grad + (self.grad * 1)

The self.grad * 1 is the chain rule in action. Where 1 is the gradient of an addition operation. y = x + w, dy/dx = 1. We’re multiplying that by whatever gradients are coming down from top. In this case, dz/dy. Therefore, the gradient coming to x (the dep in self.deps) from z through y (self) is dz/dy * dy/dx i.e. self.grad * 1.

  graph LR
x --"add"--> y
y --"add"--> z

If instead the operation from x to y were multiplication, the gradient would be different. Therefore, we need to track the operation that relates a node to its dependencies. Such that, the new gradient update line should become:

1
 dep.grad = dep.grad + (self.grad * partial(self, dep, other))

Then:

1
2
3
4
 partial_add = lambda self, dep, other_dep: 1
 partial_mul = lambda self, dep, other_dep: other_dep.data
 partial_pow = lambda self, dep, other_dep: other_dep.data * dep.data ** (other_dep.data-1)
 partial_exp = lambda self, dep, other_dep: self.data

This size-two tuple (dep, other_dep) works because all operations can be represented as a binary tree. For example x * y * z is (x * y) * z.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
class Value:
    def __init__(self, data, grad=None, deps=(), partials=()):
        self.data = data
        self.grad = grad
        self.deps = deps
        self.partials = partials
    def __repr__(self): return f"V({self.data}, {self.grad})"
    def __add__(self, other):
        data = self.data + other.data
        deps = (self, other)
        partials = (
            lambda self, dep, other_dep: 1,
            lambda self, dep, other_dep: 1
        )
        return Value(data=data, grad=None, deps=deps, partials=partials)
    def __mul__(self, other):
        data = self.data * other.data
        deps = (self, other)
        partials = (
            lambda self, dep, other_dep: other_dep.data,
            lambda self, dep, other_dep: other_dep.data
        )
        return Value(data=data, grad=None, deps=deps, partials=partials)
    def backward(self):
        # The root node: d(root)/d root = 1
        if self.grad is None:
            self.grad = 1
        if not self.deps:
            return # root node reached
        dep, *other = self.deps
        partial, *other_partial = self.partials

        if other:
            other = other[0]
            other_partial = other_partial[0]

        # This is the first time the dependency is seen.
        # It does not have any gradients accumulated.
        if dep.grad is None:
            dep.grad = 0
        # accumulating edges = last total + gradient of current edge
        dep.grad = dep.grad + (self.grad * partial(self, dep, other))
        dep.backward()

        if other:
            # This is the first time the dependency is seen.
            # It does not have any gradients accumulated.
            if other.grad is None:
                other.grad = 0
            # accumulating edges = last total + gradient of current edge
            other.grad = other.grad + (self.grad * other_partial(self, other, dep))
            other.backward()

Let’s try it out:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
w = Value(2)
x = Value(1)
y = w * x
z = y + x
# z = (w*x) + x = wx + x
# dz/dx = w+1, dz/dy = 1, dz/dw = x
print("z", z.data)

z.backward()
print(f"dz/dz: {z.grad}")
print(f"dz/dy: {y.grad}")
print(f"dz/dx: {x.grad}")
print(f"dz/dw: {w.grad}")

We can clean this up a bit. Creating a class-level attribute to store partial derivative functions for supported operations. There are three kinds of operations:

Symmetric binary. The partial function is the same for both dependencies. For example z = x+y; dz/dx = dz/dy = 1. Same for multiplication; z = x*y; dz/dx=y, dz/dy=x i.e. dz/d (one dependency) = other dependency.
Unary operations. The operation only has one dependency. For example $e^x, \sin(x)$.
Unsymmetric binary. The partial function is different for each dependency. For example $z=x^y$.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
import math

class Value:
    _partials = {
        '+': lambda self, dep, other: 1,
        '*': lambda self, dep, other: other.data,
        '_^': lambda self, dep, other: other.data * dep.data ** (other.data - 1),
        '^_': lambda self, dep, other: self.data * math.log(other.data),
        'e': lambda self, dep, other: self.data,
    }
    def __init__(self, data, grad=None, deps=(), partials=()):
        self.data = data
        self.grad = grad
        self.deps = deps
        self.partials = partials
    def __repr__(self): return f"V({self.data}, {self.grad})"
    def __add__(self, other):
        data = self.data + other.data
        deps = (self, other)
        partials = (self._partials['+'], self._partials['+'])
        return Value(data=data, grad=None, deps=deps, partials=partials)
    def __mul__(self, other):
        data = self.data * other.data
        deps = (self, other)
        partials = (self._partials['*'], self._partials['*'])
        return Value(data=data, grad=None, deps=deps, partials=partials)
    def __pow__(self, other):
        data = self.data**other.data
        deps = (self, other)
        partials = (self._partials['_^'], self._partials['^_'])
        return Value(data=data, grad=None, deps=deps, partials=partials)
    def backward(self):
        # The root node: d(root)/d root = 1
        if self.grad is None:
            self.grad = 1
        if not self.deps:
            return # root node reached
        dep, *other = self.deps
        partial, *other_partial = self.partials

        if other:
            other = other[0]
            other_partial = other_partial[0]

        # This is the first time the dependency is seen.
        # It does not have any gradients accumulated.
        if dep.grad is None:
            dep.grad = 0
        # accumulating edges = last total + gradient of current edge
        dep.grad = dep.grad + (self.grad * partial(self, dep, other))
        dep.backward()

        if other_partial is not None:
            # This is the first time the dependency is seen.
            # It does not have any gradients accumulated.
            if other.grad is None:
                other.grad = 0
            # accumulating edges = last total + gradient of current edge
            other.grad = other.grad + (self.grad * other_partial(self, other, dep))
            other.backward()

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
w = Value(2)
x = Value(2)
y = w * x
z = y + x**Value(2)
# z = (w*x) + x**2 = wx + x
# dz/dx = w+2x, dz/dy = 1, dz/dw = x
print("z", z.data)

z.backward()
print(f"dz/dz: {z.grad}")
print(f"dz/dy: {y.grad}")
print(f"dz/dx: {x.grad}")
print(f"dz/dw: {w.grad}")

Homework: how to take higher order derivatives? Grads of grads? Hint: the grad attribute is calculated by the same operations as the original computation graph: add/multiply/exp. Then, it can be wrapped in a Value too, right? If so, we can call backward() on it as well.

≡
